碳市场价格不确定性对电网调度影响机理分析

doi:10.16183/j.cnki.jsjtu.2023.313

摘要/Abstract

摘要：

随着全国碳市场正式上线,电力行业将在碳市场中扮演重要角色,而碳市场对电力系统低碳调度的影响机理还有待研究.首先,分析碳排放指标的年度清缴机制对电力系统日前调度的影响机理;构建年度碳市场价格的非参数概率模型,提出不同风险偏好程度的电力系统低碳经济调度方法,包括条件风险价值优化、期望值优化、鲁棒优化调度.然后,从数学优化机理层面分析碳价不确定性对电网调度的影响.由算例分析发现,与传统经济调度模型相比,低碳经济调度模型可降碳8.41%,碳市场风险厌恶程度越高,碳排放量越低;碳配额系数越小,碳市场越能够促进电网低碳运行.最后,发现碳捕集系统获利的条件为碳市场价格高于度电成本与碳捕集能耗系数的乘积.

关键词: 碳市场, 价格不确定性, 低碳经济调度, 碳捕集电厂, 风险偏好

Abstract:

With the launch of the national carbon market, electricity industry is expected to play an important role in the carbon market. However, the impact mechanism of carbon market on low-carbon scheduling in power systems remains underexplored and warrants further study. This paper investigates the impact of the annual clearing mechanism in the carbon market on the day-ahead dispatch of power systems. A non-parametric statistical model is developed to annual represent the carbon market price. Considering the uncertainty in carbon price, this paper proposes several low-carbon economic dispatch methods for power systems with different risk preferences, including conditional value at risk (CVaR) optimization, expected value optimization, and robust optimization. The impact of carbon price uncertainty on day-ahead dispatch is analyzed through a mathematical optimization framework. The results show that, compared with traditional economic dispatch models, the low-carbon economic dispatch model can reduce carbon emissions by 8.41%. Additionally, the more risk-averse the approach to carbon pricing, the lower the carbon emissions. The smaller carbon quota coefficient further promotes low-carbon dispatch through the carbon market. Finally, this paper identifies conditions under which carbon capture systems become profitable, specifically, when the carbon price in the market exceeds the product of the unit generation cost and the energy consumption coefficient of carbon capture.

Key words: carbon market, price uncertainty, low-carbon dispatch, carbon capture power plant, risk preference

中图分类号:

TM731

吴静, 刘轩宇, 李响, 齐笑言, 李成俊, 张忠. 碳市场价格不确定性对电网调度影响机理分析[J]. 上海交通大学学报, 2025, 59(3): 354-364.

WU Jing, LIU Xuanyu, LI Xiang, QI Xiaoyan, LI Chengjun, ZHANG Zhong. Impact Mechanism Analysis of Carbon Price Uncertainty on Power System Dispatch[J]. Journal of Shanghai Jiao Tong University, 2025, 59(3): 354-364.

图/表 13

图1

图2

表1

图3

表2

图4

图5

表3

图6

图7

图8

表4

表5

参考文献 23

[1]	庞腊成, 吉斌, 徐帆, 等. 面向电-碳市场协同的负荷响应机制与效益分析初探[J]. 电力系统自动化, 2022, 46(22): 62-71.
	PANG Lacheng, JI Bin, XU Fan, et al. Preliminary study on mechanism and benefit analysis of load response for electricity-carbon market collaboration[J]. Automation of Electric Power Systems, 2022, 46(22): 62-71.
[2]	梅天华, 边巧燕, 谢俊, 等. 考虑碳排放权的低碳电力调度及收益分摊[J]. 电力系统自动化, 2016, 40(22): 49-55.
	MEI Tianhua, BIAN Qiaoyan, XIE Jun, et al. Low-carbon power dispatching and benefit allocation considering carbon emission allowance[J]. Automation of Electric Power Systems, 2016, 40(22): 49-55.
[3]	张刚, 张峰, 张利, 等. 考虑碳排放交易的日前调度双阶段鲁棒优化模型[J]. 中国电机工程学报, 2018, 38(18): 5490-5499.
	ZHANG Gang, ZHANG Feng, ZHANG Li, et al. Two-stage robust optimization model of day-ahead scheduling considering carbon emissions trading[J]. Proceedings of the CSEE, 2018, 38(18): 5490-5499.
[4]	周任军, 孙洪, 唐夏菲, 等. 双碳量约束下风电-碳捕集虚拟电厂低碳经济调度[J]. 中国电机工程学, 2018, 38(6): 1675-1683.
	ZHOU Renjun, SUN Hong, TANG Xiafei, et al. Low-carbon economic dispatch based on virtual power plant made up of carbon capture unit and wind power under double carbon constraint[J]. Proceedings of the CSEE, 2018, 38(6): 1675-1683.
[5]	陈锦鹏, 胡志坚, 陈嘉滨, 等. 考虑阶梯式碳交易与供需灵活双响应的综合能源系统优化调度[J]. 高电压技术, 2021, 47(9): 3094-3104.
	CHEN Jinpeng, HU Zhijian, CHEN Jiabin, et al. Optimal dispatch of integrated energy system considering ladder-type carbon trading and flexible double response of supply and demand[J]. High Voltage Engineering, 2021, 47(9): 3094-3104.
[6]	彭思佳, 邢海军, 成明洋. 多重不确定环境下考虑阶梯型碳交易的虚拟电厂低碳经济调度[J]. 上海交通大学学报, 2023, 57(12): 1571-1582. doi: 10.16183/j.cnki.jsjtu.2022.185
	PENG Sijia, XING Haijun, CHENG Mingyang. Low carbon economic dispatch of virtual power plants considering ladder-type carbon trading under multiple unceritainties[J]. Journal of Shanghai Jiao Tong University, 2023, 57(12): 1571-1582.
[7]	尚楠, 陈政, 卢治霖, 等. 电力市场、碳市场及绿证市场互动机理及协调机制[J]. 电网技术, 2023, 47(1): 142-154.
	SHANG Nan, CHEN Zheng, LU Zhilin, et al. Interaction principle and cohesive mechanism between electricity market, carbon market and green power certificate market[J]. Power System Technology, 2023, 47(1): 142-154.
[8]	陈厚合, 茅文玲, 张儒峰, 等. 基于碳排放流理论的电力系统源-荷协调低碳优化调度[J]. 电力系统保护与控制, 2021, 49(10): 1-11.
	CHEN Houhe, MAO Wenling, ZHANG Rufeng, et al. Low-carbon optimal scheduling of a power system source-load considering coordination based on carbon emission flow theory[J]. Power System Protection & Control, 2021, 49(10): 1-11.
[9]	朱晔, 兰贞波, 隗震, 等. 考虑碳排放成本的风光储多能互补系统优化运行研究[J]. 电力系统保护与控制, 2019, 47(10): 127-133.
	ZHU Ye, LAN Zhenbo, WEI Zhen, et al. Research on optimal operation of wind-PV-ES complementary system considering carbon emission cost[J]. Power System Protection & Control, 2019, 47(10): 127-133.
[10]	薛贵挺, 汪柳君, 刘哲, 等. 考虑碳排放的光储充一体站日前运行策略[J]. 电力系统保护与控制, 2022, 50(7): 103-110.
	XUE Guiting, WANG Liujun, LIU Zhe, et al. Day-ahead operation strategy of an integrated photovoltaic storage and charging station considering carbon emissions[J]. Power System Protection & Control, 2022, 50(7): 103-110.
[11]	韩海腾, 魏恬恬, 周亦洲, 等. 考虑碳排放的含产消者多主体博弈协同调度策略研究[J]. 电网技术, 2022, 46(11): 4238-4248.
	HAN Haiteng, WEI Tiantian, ZHOU Yizhou, et al. Research on cooperative dispatch strategy of multi-agent game including prosumers considering carbon emissions[J]. Power System Technology, 2022, 46(11): 4238-4248.
[12]	刘子旭, 米阳, 卢长坤, 等. 计及需求响应和风力发电消纳的电-热系统低碳优化调度[J]. 上海交通大学学报, 2023, 57(7): 835-844. doi: 10.16183/j.cnki.jsjtu.2022.056
	LIU Zixu, MI Yang, LU Changkun, et al. Low-carbon optimal dispatch of electric-thermal system considering demand response and wind power consumtion[J]. Journal of Shanghai Jiao Tong University, 2023, 57(7): 835-844.
[13]	林森, 文书礼, 朱淼, 等. 考虑碳交易机制的海港综合能源系统电-热混合储能优化配置[J]. 上海交通大学学报, 2024, 58(9): 1344-1356. doi: 10.16183/j.cnki.jsjtu.2022.428
	LIN Sen, WEN Shuli, ZHU Miao, et al. Seaport integrated energy system considering carbon trading mechanism[J]. Journal of Shanghai Jiao Tong University, 2024, 58(9): 1344-1356.
[14]	卢志刚, 隋玉珊, 冯涛, 等. 考虑储热装置与碳捕集设备的风电消纳低碳经济调度[J]. 电工技术学报, 2016, 31(17): 41-51.
	LU Zhigang, SUI Yushan, FENG Tao, et al. Wind power accommodation low-carbon economic dispatch considering heat accumulator and carbon capture devices[J]. Transactions of China Electrotechnical Society, 2016, 31(17): 41-51.
[15]	崔杨, 曾鹏, 王铮, 等. 考虑碳捕集电厂能量转移特性的弃风消纳多时间尺度调度策略[J]. 中国电机工程学报, 2021, 41(3): 946-961.
	CUI Yang, ZENG Peng, WANG Zheng, et al. Multiple time scales scheduling strategy of wind power accommodation considering energy transfer characteristics of carbon capture power plant[J]. Proceedings of the CSEE, 2021, 41(3): 946-961.
[16]	刘牧心, 梁希, 林千果, 等. 碳中和驱动下CCUS项目衔接碳交易市场的关键问题和对策分析[J]. 中国电机工程学报, 2021, 41(14): 4731-4739.
	LIU Muxin, LIANG Xi, LIN Qianguo, et al. Key issues and countermeasures of ccus projects linking carbon emission trading market under the target of carbon neutrality[J]. Proceedings of the CSEE, 2021, 41(14): 4731-4739.
[17]	叶晨, 牟玉亭, 王蓓蓓, 等. 考虑动态碳交易曲线的电-碳市场出清模型及节点边际电价构成机理分析[J]. 电网技术, 2023, 47(2): 613-624.
	YE Chen, MOU Yuting, WANG Beibei, et al. Mechanism of locational marginal prices and clearing model of electricity and carbon market considering dynamic carbon trading curve[J]. Power System Technology, 2023, 47(2): 613-624.
[18]	杨玉强, 徐程炜, 邓晖. 碳市场与电力市场协同运行关键问题研究[J]. 浙江电力, 2023, 42(5): 66-75.
	YANG Yuqiang, XU Chengwei, DENG Hui. A study of key issues in the coordinated operation between carbon market and electricity market[J]. Zhejiang Electric Power, 2023, 42(5): 66-75.
[19]	黄杰, 薛禹胜, 蒋超, 等. 碳市场风险的分析与控制: (一)框架设计[J]. 电力系统自动化, 2018, 42(12): 11-18.
	HUANG Jie, XUE Yusheng, JIANG Chao, et al. Carbon market risk analysis and control: Part I, framework design[J]. Automation of Electric Power Systems, 2018, 42(12): 11-18.
[20]	郭静蓉, 向月, 吴佳婕, 等. 考虑CCUS电转气技术及碳市场风险的电-气综合能源系统低碳调度[J]. 中国电机工程学报, 2023, 43(4): 1290-1303.
	GUO Jingrong, XIANG Yue, WU Jiajie, et al. Low-carbon optimal scheduling of integrated electricity-gas energy systems considering CCUS-P2G technology and risk of carbon market[J]. Proceedings of the CSEE, 2023, 43(4): 1290-1303.
[21]	赵麟, 李亚鹏, 靳晓雨, 等. 考虑CCER机制的碳-电耦合市场中水火电协同竞价模型[J]. 电力系统自动化, 2023, 47(21): 12-24.
	ZHAO Lin, LI Yapeng, JIN Xiaoyu, et al. Coordinated bidding model of hydropower-thermal power in carbon-electricity coupling market considering CCER mechanism[J]. Automation of Electric Power Systems, 2023, 47(21): 12-24.
[22]	马君明, 李惠, 兰成明, 等. 基于拒绝抽样算法的结构体系可靠度更新[J]. 工程力学, 2022, 39(3): 11-22.
	MA Junming, LI Hui, LAN Chengming. System reliability updating based on the rejection sampling algorithm[J]. Engineering mechanics, 2022, 39(3): 11-22.
[23]	赵书强, 要金铭, 李志伟. 基于改进K-means聚类和SBR算法的风电场景缩减方法研究[J]. 电网技术, 2021, 45(10): 3947-3954.
	ZHAO Shuqian, YAO Jinming, LI Zhiwei. Wind power scenario reduction based on improved K-means clustering and SBR algorithm[J]. Power System Technology, 2021, 45(10): 3947-3954.

编辑推荐 0

Metrics

阅读次数

全文

134

HTML			PDF

最新录用	在线预览	正式出版	最新录用	在线预览	正式出版
0	0	0	128	0	6

来源	本网站	其他网站

次数	45	89
比例	34%	66%

摘要

154

最新录用	在线预览	正式出版

108	0	46

来源	本网站	其他网站

次数	45	109
比例	29%	71%

机组	最小出力/MW	最大出力/MW	煤/气耗系数			煤/气碳排放系数/%	燃料价格/ (元·t^-1)
机组	最小出力/MW	最大出力/MW	a/[t·(MW·h)^-1]	b/[t·(MW·h)^-1]	c/t	煤/气碳排放系数/%	燃料价格/ (元·t^-1)
G1	80	200	0.000338	0.2298	4.98	2.3	1246
G2	60	150	0.000421	0.2127	4.30	2.8	1246
G3	25	80	0.000328	0.1230	1.50	2.2	2400

分位数水平/%	碳价/(元·t^-1)	分位数水平/%	碳价/(元·t^-1)
5	50.5	55	58.2
10	56.3	60	58.4
15	56.7	65	58.6
20	57	70	58.7
25	57.2	75	59.1
30	57.4	80	59.4
35	57.6	85	59.7
40	57.8	90	60.2
45	57.9	95	61.6
50	58.1

ξ	总燃料成本/元	总碳排放成本/元	总碳排放量/t
0.0	2 316 119	154 574	5 406
0.5	2 316 368	154 333	5 400
1.0	2 317 891	152 943	5 370
2.0	2 318 030	152 819	5 367
5.0	2 318 172	152 697	5 364

低碳经济模型	模型参数	碳排放/t	燃气机组G3启停状态0:00-24:00
期望值模型	ε_i	5366	000000001111111111111100
	ε_i/2	5133	111111111111111111111111
CVaR模型	ξ=0	5406	000000000111111111111100
	ξ=1	5370	000000001111111111111100
	ξ=2	5367	000000001111111111111100
鲁棒模型	Γ=1	5132	111111111111111111111111
	Γ=0.5	5366	000000001111111111111100
不考虑碳排放模型		5859	000000000000000000000000

碳配额系数/%	总燃料成本/元	总碳排放成本/元	总碳排放量/t
125	2 317 975	141 529	5 368
100	2 318 086	175 667	5 366
75	2 318 199	209 798	5 364
50	2 330 841	230 378	5 133
